ARRAYS
If we need
to store 5 integer values, we had learnt so far to declare 5 different integer variables
with separate identifier names. Instead of that, lets us now learn to use one location
with one name, to store these 5 integer values - using arrays.
An array is
a collection of data belonging to similar data type that are stored in
sequential memory locations, and are accessed using a common name indexed by integers.
int a[5] is an array named ‘a’ that can store 5 integer
values at continuous memory locations that are indexed as:
a[0], a[1], a[2], a[3], a[4]
The
integer array a[5] holds 5 integer
values identified by name ‘a’ and is graphically represented like
this:
Here, each blank panel represents an integer element of the
array. These elements are numbered from 0
to 4 since in arrays the first index always starts with 0.
TYPES OF ARRAYS
There are two
types of arrays: One-dimensional array and Two-dimensional array.
A one-dimensional array is like
a "data list" with one row and several columns or, one column and several
rows.
A two-dimensional array (multi-dimensional) is like a "data table" with several rows and
several columns.
ARRAY DECLARATION
An array
must be declared before it is used. Declaration syntax of array is:
data type name [elements];
where data type can be int, float, char…etc., name
is a valid identifier and elements enclosed in square brackets
specify the total number of values the array would store. E.g. int a[5]
An array
element represents the indices, or the number of elements the array is
going to hold. Since recent versions of
C++ supports dynamic memory allocation for arrays, the size of an array need
not be strictly specified at declaration.
When an array is declared, initial values can be stored into
each of its locations. These values may or may not change in the program. The process of assigning initial data
values to array elements is called Array Initialization. We can initialize
an array with initial values and with dynamic
values.
(i) Array initialization
along with declaration: Initial
values are assigned to an array by specifying the element count and enclosing
the data values within curly braces.
E.g. int a[5] = { 24, 28, 38, 12, 1498 };
Above declaration creates
an integer array with element count 5 and data values 24, 28, 38, 12, 1498. It
can be represented as below:
C++ also allows the possibility of not specifying the element
count within square brackets by keeping it empty [ ]. In this case, the
compiler will assume a size for the array that matches the number of values
included between braces.
E.g. int a[ ] = { 24,
28, 38, 12, 1498};
In the
above declaration, array ‘a’ will be
automatically assigned 5 memory locations, because 5 values have been
initialized.
(ii) Array initialization with dynamic values: Dynamic values are assigned to an array at run time, mostly
using loops. For example, look at the following code:
int a[10];
for (int i=0; i<10;++i)
a[i]=i+5;
Here,
an array ‘a’ is declared with element count 10. Using for loop, a[0] is assigned value 5, a[1] is assigned 6, a[2] is assigned 7 and so on, until a[9] which is assigned value 14.
Accessing the Values of an Array
The format for accessing values in an array is:
name[index]
From previous example,
array ‘a’ has 5 integers with following reference names for each of the element:
a[0], a[1],
a[2], a[3], a[4]
To store
the value 75 into the third element of array “a”, we write:
a[2] = 75;
To assign
the value of third element of array “a”
to variable “b”, we write:
b = a[2];
Note: Array
locations start from 0 and so first array element is a[0]…third is a[2]
In C++ it
is syntactically correct to exceed the
valid range of indices for an array. This can create problems, since
accessing out-of-range elements do not cause compilation errors but can cause runtime errors.
There are
2 uses of square brackets [ ] in
arrays. One is to specify the size of arrays when they are declared. Second one
is to specify indices for accessing array elements. Here are 2 examples:
int a[5]; // declaration of a new array
a[2] = 75; //
access to an element of the array
PROGRAM 31
Q. Write a program to initialize an integer array and display
the values.
|
#include
<iostream>
using
namespace std;
int a[] =
{28, 12, 18, 9, 38};
int i;
main ()
{
cout<<"Array Values are\n";
for (i=0 ; i<5 ; i++)
{
cout << a[i] <<"\n";
}
}
|
PROGRAM 32
Q. Write a program to accept ‘n’ numbers into an array, display
them and print their sum.
|
#include<iostream>
#define SIZE 100
using namespace std;
main()
{
int ar[SIZE],n,i,
sum=0;
cout<<"How
many array elements? "; cin>>n;
/* input numbers into array
*/
cout<<"Enter
the numbers: \n";
for(i=0; i<n; i++)
{
cin>>ar[i];
sum+=ar[i];
}
/*Print values from the
array*/
cout<<"The
entered numbers are: \n";
for(i=0; i<n; i++)
cout<<ar[i]<<endl;
cout<<"Sum of numbers in array
is:\n"<<sum;
}
|
OUTPUT
Program 33
Q. Assign the names of 4 districts in a string array and display the 3rd
district.
|
#include<iostream>
using namespace std;
main()
{
string
district[4] = {"Kollam", "Ernakulam",
"Trissur", "Wayanad"};
cout
<< "Fourth District is: "<< district[3];
}
|
OUTPUT
MULTI DIMENSIONAL ARRAYS
Multidimensional (bi-dimensional) arrays can be described as an
“array of arrays” that is made up of elements of the same data type. A multi-dimensional array has
rows and columns. Syntax for declaration of multi-dimensional array is:
ArrayName [index1][index2]
where index1 is the
Rows and index2 is the Columns.
A bi-dimensional array can be imagined as a bi-dimensional
table of data that are made up of elements, all of them of the same data type.
In the above memory illustration, jimmy represents a bi-dimensional array
of 3 per
5 (3 by 5 or 3 X 5) elements of type int.
Format to declare this array in C++ is:
int jimmy [3][5];
Referring
a Multi-Dimensional Array: The way to reference the second element
vertically and fourth horizontally in an expression would be:
jimmy[1][3]
(remember that
array indices always begin with zero)
Multidimensional
arrays are not limited to two dimensions. They can contain as many indices as
needed. But be careful! The amount of memory needed for an array rapidly
increases with each dimension. For example:
char century [100][365][24][60][60];
It declares an
array with a char element for each second
in a century, that is more than 3 billion chars. So this declaration
would consume more than 3 gigabytes of memory !
PROGRAM 34
Q. Write a
program to accept values into two 3X3 matrix arrays and
find its SUM.
#include<iostream> using namespace std;
main()
{
int a[3][3], b[3][3], s[3][3];
int i, j ;
cout<<“Enter values for the first
matrix\n”;
for(i=0;i<3;i++)
for(j=0;j<3;j++)
cin>>a[i][j];
cout<<“Enter values for the second
matrix\n”;
for(i=0;i<3;i++)
for(j=0;j<3;j++)
cin>>b[i][j];
/* calculate the sum */
for(i=0;i<3;i++)
for(j=0;j<3;j++)
s[i][j]=a[i][j]+b[i][j];
cout<<“\n SUM MATRIX \n”;
for(i=0;i<3;i++)
{
cout<<endl;
for(j=0;j<3;j++)
cout<<“\t”<<s[i][j];
}
}
|
OUTPUT
Enter values
for the first matrix
10 20 30
11 22 33
15 25 46
Enter values
for the second matrix
5 8 9
9 5 4
10 40 12
SUM MATRIX
15 28 39
20 27 37
25 65 58
|
POINTERS
Pointer is
a variable that holds memory address of another variable. In C++, you can convert one type of pointer into another using
explicit type cast. Pointers are memory addresses that:
1.
Points to variables,
arrays, functions, strings, structures, class.
2.
Can be
returned from a function.
3.
Supports dynamic
memory allocation.
4. Helps
to interchange values within variables without physically moving them.
Pointer
Variables
A variable that points to the memory address of data storage location is
called the pointer variable. It can be declared by a base type, and a pointer (*) to the variable name. Syntax for declaring a pointer variable is: type *name;
For
example: int *ptr;
simply
means that ptr is a pointer to an integer.
Pointer Operators
There are
two special pointer operators * and &.
1. & is a unary operator that returns the memory address of its operand. It is also called address operator. Eg: ptr =
&a;
2. * is a unary operator that
returns the value located at the address pointed. It
is specifically called the pointer operator
and is also called the “Value at” operator or the “Indirection” operator. Eg: *ptr
Following program will help you clarify what we
just learned. Please also check Chapter 3, Program 12.
Program 35
Q. Write a
program to declare an integer variable (with initial value). Declare an integer
pointer and point it to the variable. Display memory address and data value using
the pointer.
|
#include
<iostream>
using
namespace std;
main()
{
int a
= 10;
int *ptr;
ptr =
&a; // pointer ‘ptr’ is assigned address of variable ‘a’
cout << “Address pointed by ptr = ” <<
ptr;
cout << “Value within Address Pointer
ptr = ” << *ptr;
}
|
OUTPUT
POINTER EXPRESSIONS
Expressions
involving pointers conform to the same rules as other expressions. This section
examines a few special aspects of pointer expressions.
Pointer Assignment: As with any variable, you may use a pointer on the right-hand
side of an assignment statement to assign its value to another pointer. For
example,
#include
<iostream.h>
void main()
{
int x ;
int *p1, *p2;
p1 = &x;
p2 = p1;
cout<< p2;
/* prints the address of x, not value of x */
}
Pointer Arithmetic: There are
only two arithmetic operations that you may use on pointers: addition and subtraction. Now let’s consider
the following expressions:
1.
++ptr // ptr = ptr + sizeof (data-type)
Increases memory address by 1. If ptr is of type
int and ptr = 2000, then ++ptr would
store memory address 2002, not 2001.
The reason for this is that each time ptr is incremented, it will point
to the next integer which is 2 bytes away. The same is true of decrements.
Note : Memory space occupied by integer is 2 bytes.
2. - -ptr // ptr = ptr -
sizeof (data-type)
Decreases memory address by 1. If ptr is of type
int and ptr = 2000, then - -ptr would
store memory address 1998 (2 Bytes less than 2000).
3. ++*ptr // ++(*ptr) : Add 1 to value pointed by *ptr
Increase the value that is located at address pointer ptr, by 1.
int a = 10;
int *ptr;
cout<< ++*ptr ;
Above code prints 11 (value pointed by ptr
+ 1, OR, 10+1)
4. --*ptr // - - (*ptr)
:
Subtract 1 from value pointed by *ptr
Decrease the value which is located at address
pointer ptr, by 1
For example:
int a = 10;
int *ptr;
cout<< - -*ptr ;
Above
code prints 9 (value pointed by ptr - 1, OR, 10-1)
General
Rules for Pointer Arithmetics:
Each
time a pointer is incremented, it points to the memory location of the next
element of its base type. Each time it is decremented, it points to the
location of the previous element. When applied to character pointers, this will
appear as “normal” arithmetic because characters are always 1 Byte long. All
other pointers will increase or decrease by the length of the data type they
point to. You can also add or subtract integers to or from pointers.
The expression:
p1 = p1
+ 12;
makes p1
point to the twelfth element of p1’s type beyond the one it currently points
to.
PROGRAM 36
Q. Using Pointers, interchange the values of two integer variables.
#include<iostream> using namespace std;
main()
{
int var1=100, var2=200,t;
int *ptr1,*ptr2;
ptr1=&var1;
ptr2=&var2;
cout<<“\n Before changing the values\n”;
cout<<“\n Variable 1 :
“<<var1;
cout<<“\n Variable 2 :
“<<var2;
/* Interchanging values using pointers */
t=*ptr1;
*ptr1=*ptr2;
*ptr2=t;
cout<<“\n After changing the values\n”;
cout<<“\n Variable 1 :
“<<var1;
cout<<“\n Variable 2 :
“<<var2;
}
|
OUTPUT
Before changing the
value
Variable 1 :
100
Variable 2 :
200
After changing the
value
Variable 1 :
200
Variable 2 :
100
|
DYNAMIC
MEMORY
Until
now, in all our programs, we have used fixed memory that was made available as
per variable declaration at the start. But, what if we need a variable amount
of memory that can only be determined during runtime? For example, in the case
that we need some user input to determine the necessary amount of memory space.
The answer is dynamic memory, for which C++ integrates the operators new
and delete.
(a)
Operators: new and new[]
The
operator new is used to request allocation
of dynamic memory. new is followed by
a data
type specifier and the total number of memory locations to be allocated within square
brackets []. It returns a pointer to the beginning of the new block of memory that
is allocated. General syntax are:
pointer = new
type;
pointer = new type [number_of_elements];
The
first expression is used to allocate memory to contain one single element of specific
type. The second one is used to
assign a block (an array) of elements of specific type, where number_of_elements is an integer value representing the
number of elements. For example:
int * bobby;
bobby = new int
[5];
In this
case, the system dynamically assigns space for five elements of type int
and returns a pointer to the first element of the sequence, which is assigned
to bobby. Therefore, now, bobby points to a valid block of memory with space
for five elements of type int.
The first element pointed by bobby can be
accessed either with the expression bobby[0] or the expression *bobby. The
second element can be accessed either with bobby[1] or *(bobby+1) and so on.
You could be wondering the difference between
declaring a normal array and assigning dynamic memory to a pointer, as we have
just done. The most important difference is that the size of an array has to be
a constant value, which limits its size to what we decide at the moment of
designing the program, before its execution, whereas the dynamic memory
allocation allows us to assign memory during the execution of the program
(runtime) using any variable or constant value as its size.
The dynamic
memory requested by our program is allocated by the system from the memory
heap. However, computer memory is a limited resource, and it can be exhausted.
Therefore, it is important to have some mechanism to check if our request to
allocate memory was successful or not.
C++ provides two standard methods to
check if the memory allocation was successful:
1.
By handling exceptions. Using this method an exception of type bad_alloc
is thrown when the allocation fails. This exception method is the default
method used by new, and is the one used in a declaration like:
bobby = new int
[5]; // if it fails an exception is thrown
Note: Exceptions are a powerful
C++ feature that checks if statements (between blocks) are successfully
executed for unseen errors like for example, trying to allocate memory when
there’s no memory space left.
2.
The nothrow method: In this method, when a memory
allocation fails, instead of throwing a bad_alloc
exception or terminating the program, the pointer returned by new is a null pointer, and the program continues its execution. This method
can be specified by using a special object called nothrow as parameter for
new:
bobby = new
(nothrow) int [5];
In
this case, if the allocation of this block of memory failed, the failure could
be detected by checking if bobby took a null pointer value:
int * bobby; bobby
= new (nothrow) int [5];
if (bobby == 0)
{
// error assigning memory. Take
measures.
};
This
nothrow method requires more work
than the exception method, since the value returned has to be checked after each
and every memory allocation. Anyway this method can become tedious for larger
projects, where the exception method is generally preferred.
(b)
Operator: delete and delete[]
Since
the necessity of dynamic memory is usually limited to specific moments within a
program, once it is no longer needed it should be freed so that the memory
becomes available again for other requests of dynamic memory. This is the
purpose of the operator delete, whose
format is:
delete
pointer;
delete
[] pointer;
The expression delete pointer; should be
used to delete memory allocated for a single element, and the expression delete [] pointer; is used when memory is allocated for
an array of elements.
The
value passed as argument to delete
must be either a pointer to a memory block previously allocated with new, or a null pointer (in the case of a
null pointer, delete produces no effect).
PROGRAM 37
Q. Enter “n” integers using dynamic memory
allocation. Ensure successful allocation and freeing of memory.
main () { int i, n; int * p; char x; cout << "How many numbers would you like to type? "; cin >> i; p= new (nothrow) int[i]; if (p == 0) cout << "Error: memory could not be allocated"; else { for (n=0; n<i; n++) { cout << "Enter number: "; cin >> p[n]; } cout << "You have entered: "; for (n=0; n<i; n++) cout << p[n] << ", "; delete[] p; } cout << "\nAfter memory deallocation\n"; for (n=0; n<i; n++) cout << p[n] << ", "; }
|
OUTPUT
Notice
how the value within brackets in the new statement is a variable value i entered by the user, not a constant
value:
p= new (nothrow) int[i];
It is a good practice to always check
if a dynamic memory block was successfully allocated. Therefore, if you use the
nothrow method, you should always check the value of the pointer returned.
Otherwise, use the exception method, even if you do not handle the exception.
This way, the program will terminate at that point without causing the
unexpected results of continuing executing a code that assumes a block of
memory to have been allocated when in fact it has not.
STRING
A String is an array of characters (char). There are
specific functions that can be used for strings, like adding to strings,
finding the length of strings, and also checking to see if strings match. The
definition of a String would be
anything that contains more than one character strung (joined) together. For
example, “This” is a string. String
literals are words surrounded by double quotation marks. Example: “This is
a static string”
A
string constant is a one dimensional
array of characters terminated by a null ('\0’). For example,
char name[ ] = {
‘I’, ’N’, ’F’, ’O’, ’S’, ’Y’, ’S’, ’\0’};
Each
character in the array occupies one byte of memory and the last character is
always ‘\0’. What character is this? It looks like two characters, but it is
actually only one character, with the \
indicating that what follows it is something special. ‘\0’ is called null
character. Note that ‘\0’ and ‘0’ are not same. The terminating null (‘\0’) is
important, because it is the only way the function that work with a string can
know where the string ends. In fact, a string not terminated by a ‘\0’ is not
really a string, but merely a collection of characters.
C++
provides a shortcut for initializing string. For example, the string used above
can also be initialized as,
char
name[ ] = “INFOSYS” ;
Note
that in this declaration ‘\0’ is not necessary. C++ inserts the null character
automatically.
Note: There is a
difference between a character and a string. A character takes only a single
byte to store a character where as a string takes one extra character to store
the null value. The
examples below show the difference.
char a[ ] = ’A’ /* a is declared as a character */
This is
how a is stored in memory
char b[ ] = ”A” /* b is declared
as a string */
This is
how b is stored in memory
char c[50];
Declaring
a string of 49 letters
The
last example would declare a string with a length of 50
characters. Do not forget that arrays begin at zero, not 1 for the index
number. In addition, a string ends with a null character, literally a ‘\0’
character. However, just remember that there will be an extra character on the
end on a string. It is like a period at the end of a sentence, it is not
counted as a letter, but it still takes up a space. Technically, in a fifty
char array you could only hold 49 letters and one null character at the end to
terminate the string.
TAKE NOTE:
char
*arry;
This can also be used as a string. Using dynamic memory allocation,
you can declare:
arry = new char[256];
This
allows you to access arry just as if it were an array.
Keep in mind that to use delete you
must put [] between delete and arry to tell it to free all 256 bytes of memory allocated. For
example:
delete [] arry;
Strings
are useful for holding all types of long input. If you want the user to input
his or her name, you must use a string. Using cin>> to input a string
works, but it will terminate the string after it reads the first space. The
best way to handle this situation is to use the function cin.getline. The prototype for this function is:
istream& getline(char
*buffer, int length, char terminal_char);
The
char *buffer is a pointer to the
first element of the character array, so that it can actually be used to access
the array. The int length is simply
how long the string to be input can be at its maximum (how big the array is).
The char terminal_char means that the
string will terminate if the user inputs that particular character. It is
possible to make a function call of cin.getline(arry, 50); without the
terminal character. Note that ‘\n’
is the way of actually telling the compiler you mean a new line, i.e. someone
hitting the enter key.
PROGRAM 38
Q. Write a
program to accept text content for a paragraph containing multiple words and
multiple lines. Use of TAB KEY must end the paragraph. (Note:
After pressing TAB KEY, you will also have to press the Enter Key to exit from input
stream)
#include <iostream>
using namespace std;
main()
{
char
a[256];
cout<<"Please
enter Paragraph Content:\n";
cin.getline (
a, 256, '\t' );
cout<<"\nYour Paragraph
>>>\n\n"<< a <<endl;
} |
String
Library Functions
C++ compiler
comes with a large set of useful String handling Library Functions. Few commonly
used functions include: strlen(), length(), strcpy(),
strcat() and strcmp()
1.
strlen(), length()
These functions count the number of characters present in a string. Note: You can also use size()
PROGRAM 39
Q. Write a program to find the length of:
(1) “initialized”
character array,
(2) “initialized”
string,
(3) “initialized” dynamic string/characters.
#include<cstring>
#include<iostream>
using
namespace std;
main()
{
char arr[] = "Groware Education";
string s = "I am CPP student";
int len1, len2, len3;
len1 = strlen (arr);
len2 = s.length();
len3 = strlen ("IT Kerala");
cout<<"String1 = "<< arr
<<"\nLength = "<< len1<< "\n";
cout<<"String2 =
"<<s<<"\nLength = "<< len2<<
"\n";
cout<<"String3 = IT Kerala \nLength
= "<< len3;
} |
OUTPUT
2.
strcpy()
This function copies the contents of one string
into another. The base addresses of the source and target string should be
supplied to this function.
PROGRAM 40
Q. Program to copy a String from one storage location to another.
|
#include<cstring>
#include
<iostream>
using namespace std;
main()
{
char source[ ] = "Sayonara";
char target[20];
strcpy(target, source);
cout<<"\n
Source string = "<<source;
cout<<"\n
Target string = "<<target;
}
|
OUTPUT
Source string = Sayonara
Target string = Sayonara
|
3.
strcat()
This function concatenates (joins) 2 strings - the source string at
the end of target string. For example ‘Info’ and ‘Sys’ on concatenation would result into
a string ‘InfoSys’.
Note: You can also concatenate 2 strings by the plus sign (+).
For example:
string s1
= "Groware";
string s2;
s2=s1 +
" Education";
// s2 will contain "Groware Education"
PROGRAM 41
Q. Write a program to initialize two words and join them to form a single
word.
|
#include<cstring>
#include
<iostream>
using
namespace std;
main()
{
char
a[30] = "Good";
char
b[] = " Morning";
strcat
(a, b);
cout << "\n Source string =
" << b;
cout << "\n Target string =
" << a;
}
|
OUTPUT
Source String = Morning
Target String = Good
Morning
|
4.
strcmp()
This is a
function which compares two strings to find out whether they are same or
different. The two strings are compared character by character until there is a
mismatch or end of one of the strings. strcmp()
returns a zero value if both the strings are identical.
PROGRAM 42
Q. Accept two words. Compare the Two Words. Check if they
are same.
|
#include
<cstring>
#include
<iostream>
using
namespace std;
main()
{
char s1 [25];
char s2 [25];
int val;
cout << "Enter a word : ";
cin >> s1;
cout
<< "Enter another word : "; cin >> s2;
val = strcmp(s1,s2);
if (val == 0)
cout << "Same Words";
else
cout <<
"Not Same Words";
}
|
OUTPUT
2 Dimensional Array of Characters
Let’s see how 2 dimensional array of characters can be managed.
PROGRAM 43
Q. Write a program to store few names into a character
array. Then accept any name from the keyboard. Check if the accepted name is one
among the stored names.
#include<iostream>
#include<cstring>
using namespace std;
main()
{
char names[5][10] = {"akshay",
"parag", "raman", "srinivas", "gopal"};
int i, a, flag;
char n[10];
cout << "\nEnter your name: ";
cin >> n;
flag = 0;
for (i=0; i<5; i++)
{
a = strcmp (names[i], n);
if (a == 0)
{
cout << "You are Welcome" ;
flag = 1 ;
break ;
}
}
If (flag ==0)
cout <<
"Sorry, you are not a Member";
} |
OUTPUT
NOTE: You can try working out with these string functions
– find(), substr(),
swap()
PREDEFINED
MATHEMATICAL FUNCTIONS
Name Function
abs(x) absolute value
csgn(x) complex sign
sqrt(x) square root
sin(x) sine
cos(x) cosine
tan(x) tangent
exp(x) exponential function
log(x) natural logarithm
pow(x,e) power
PROGRAM 44 : Demonstrate the use of standard function “sqrt”.
#include <iostream> #include <cmath> using namespace std; main () { float x; cout<<"Please enter a number: "; cin>>x; cout<<"Square Root of "<< x <<" is "<<sqrt(x); } |
OUTPUT
Please enter a number: 81
Square Root of 81 is 9
|
No comments:
Post a Comment
